The Power to Deliver
A pair of Edge M Monoblock Power Amplifiers have the power in reserve to drive even the most demanding of speakers with punch and clarity. Because each Edge M is fully balanced from input to output, they are immune from noisy distortion and free to deliver your music exactly as the artist intended – nothing added, nothing taken away – whatever the volume.
- Fully balanced from input to output – free from noise and distortion.
- Hand picked components – hours of listening to select only those that sound the best.
- Twin Toroidal Transformers – huge reserves of power for consistent tonality.
- Cambridge Audio proprietary Class XA Amplification - no audible crossover distortion.
- Perfect partners – pair two Edge Ms with the Edge NQ to create your perfect system.
TECHNICAL SPECIFICATIONS
| CONTINUOUS POWER OUTPUT (<1% THD+N) | 200W RMS into 8 Ohms, 350W RMS into 4 Ohms |
| THD (UNWEIGHTED) | <0.002% 1kHz at rated power (8 Ohms) <0.02% 20Hz – 20kHz at rated power (8 Ohms) |
| FREQUENCY RESPONSE (INTO 8 OHM) | <3Hz – >80kHz +/-1dB |
| S/N RATIO (REF 1W INTO 8 OHM) | >93 dB |
| S/N RATIO (REF MAX POWER) | >115 dB |
| GAIN | 28dB (RCA)/ 22dB (XLR) |
| INPUT SENSITIVITY | 1.7V RMS (RCA) / 3.4V RMS (XLR) |
| INPUT IMPEDANCES | balanced 100k Ohm, unbalanced 47k Ohm |
| INPUTS | Balanced, Unbalanced |
| OUTPUTS | Speaker out, Loop out (balanced and unbalanced) |
| MAX POWER CONSUMPTION | 1000W |
| STANDBY POWER CONSUMPTION | <0.5W |
| DIMENSIONS | 150 x 460 x 405mm (5.9 x 18.1 x 15.9") |
| WEIGHT | 23.6kg (52.0lbs) |
